Automatic Filling Machine Cosmetic Paste Packaging Machine Packing Machine

Product Advantage

Technical Parameters

1. Machine type:Servo filling machine

2. Machine form:Linear type

3. Filling materials:Liquid; semi-fluid; paste; containing small particles, etc. - filling materials

4. Filling nozzles:1~24 heads

5. Filling capacity:50~5000ml

6. Production capacity:2400 bottles/hour (calculated as 1L)

7. Filling accuracy:≤0.5%

8. Suitable bottle height:100~280mm

9. Suitable bottle mouth diameter:≥∅28mm

10. Equipped functions:Leakage prevention mechanism, bottle mouth positioning mechanism, automatic cleaning function

11. Applicable industries:Food, catering, daily chemicals, medicine, tobacco and alcohol

12. Dimensions:Designed according to customer site

13. Automation level:Fully automatic

14. Use:Applicable to single machine; Applicable to connection;

15. Packaging type:Bottle, can

16. Gas source pressure:5~7kg/cm²

17. Power supply:AC220V, 50/60HZ, 2500W

18. Customized processing:Yes

Product Uses

A paste filling machine is used in various industries for filling containers with products that have a thick or viscous consistency. Common applications include:

Food Industry: Filling jars and bottles with sauces, spreads, peanut butter, honey, and dressings.

Cosmetics and Personal Care: Packaging creams, lotions, gels, and pastes in tubes or jars.

Pharmaceuticals: Filling ointments, gels, and other medicated pastes into containers.

Household Products: Filling tubes or containers with products like adhesives, pastes, or sealants.

Chemical Industry: Packaging thick chemicals, lubricants, and industrial pastes.

These machines enhance efficiency and accuracy in the filling process, ensuring consistent product quality across various applications.

Product Operate Guide

• Equipment preparation

• Prepare the paste filling machine, check whether all parts are intact, whether the fasteners of each part are loose, and tighten them if they are loose.

• Prepare the required paste and container, and select the appropriate filling head and container according to different products and specifications.

• Connect the power supply and air source.

• Check before filling

• Check whether the container is clean and free of foreign matter.

• Check whether the filling head is clean and free of residue.

• Confirm whether the paste feeding fault indicator is normal, that is, whether the paste can be fed normally.

• Check whether the air pressure is normal, and whether the filling head pressure and paste outlet pressure are appropriate.

• Check whether the printer (if any) is working properly.

• Paste filling

• Pour the paste into the paste barrel, turn on the paste feeding fault indicator, and wait for the paste to be fed.

• Place the filling head above the container and set the switch to the "on" position.

• Wait until the paste flows out of the filling head and fill it according to the set capacity. IV. Cleaning and maintenance

• Turn off the paste feeding fault indicator, pour the paste in the paste barrel into the container, and carefully clean the residue in the barrel and on the filling head.

• Clean the filling head and container, and remind them to disinfect before the next round of use.

• Check whether all parts of the equipment are intact.
